| Dimensions |
436 x 210 x 486mm(DWH) |
| Form Factor |
Mid Tower |
| Materials |
Steel + Glass |
| Mainboard Support |
ATX, Micro-ATX, ITX |
| Front Access & Controls |
Power, LED On/Off button (CX700 RGB ELITE) or LED Control Button(CX700 ARGB), USB 3.0 x 1, Type-C 3.2 Gen 2 x 1, Headphone/Mic Combo Jack
Power, Reset, USB 2.0 x 2, USB 3.0 x 1, Headphone/Mic Combo Jack (CX700 Basic) |
| Side Panel |
4mm Tempered Glass |
|
| Drive Bays |
| Expansion Slots |
7 |
| 3.5" /2.5" |
2/1 |
| 2.5" |
2 |
|
| Fan |
| Top |
3 x 120 / 2 x 140mm |
| Side |
2 x 120mm |
| Power Supply Shroud |
3 x 120mm |
| Rear |
120mm |
| Included Fan(s) |
3 x 120mm fixed mode RGB reverse fans on PSU shroud +
2 x 120mm fixed mode RGB reverse fans on right side +
1 x 120mm fixed mode RGB fan in rear
Pre-installed 2 x 120mm ARGB PWM reverse fans on right side & 1 x 120mm ARGB PWM fan in rear (CX700 ARGB) |
|
| Radiator Support |
| Top |
120 / 140 / 240 / 280 / 360mm |
| Side |
120 / 240mm |
|
| Clearance |
| Max GPU Length |
≤ 410mm
≤ 270mm (When water cooling is installed on the side) |
| Max CPU Cooler Height |
≤ 160mm |
| Max PSU Length |
≤ 210mm (With HDD cage) (Include cable)
≤ 270mm (Without HDD cage) (Not include cable) |
|
| Miscellaneous |
| Dust Filter |
Top / Bottom |
| Net Weight |
7.10 kg (CX700 RGB Elite)
6.90 Kg (CX700 ARGB)
6.39 kg (CX700 Basic) |
| Gross Weight |
8.40 kg (CX700 RGB Elite)
8.60 Kg (CX700 ARGB)
7.63 kg (CX700 Basic) |
|
